Specification
| d (Inches) | a | e | i | g | s | z | t | B1 | p | j | k | f | Bolt Size mm inch | Pillow Block Inserts | Housing No. | Weight(kg) | Material |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 1-1/8 | 5-5/16 | 3-1/16 | 7/16 | 1-1/32 | 35/64 | 1-5/16 | 1-5/8 | 1.69 | 4-21/64 | 5/16 | 23/64 | 3.54 | 7/16 | UK207;HS2307 | FC207 | 1.9 | Non-Stainless Steel |
| d (Inches) | a | e | i | g | s | z | t | B1 | p | j | k | f | Bolt Size mm inch | Pillow Block Inserts | Housing No. | Weight(kg) | Material |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 1-1/8 | 5-5/16 | 3-1/16 | 7/16 | 1-1/32 | 35/64 | 1-5/16 | 1-5/8 | 1.69 | 4-21/64 | 5/16 | 23/64 | 3.54 | 7/16 | UK207;HS2307 | FC207 | 1.9 | Non-Stainless Steel |
