Specification
| d (Inches) | a | e | i | g | s | z | t | B1 | p | j | k | f | Bolt Size mm inch | Bearing No. | Housing No. | Weight(kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 1-7/16 | 6-19/64 | 3-43/64 | 25/64 | 1-1/32 | 5/8 | 1-27/64 | 1-3/4 | 1.97 | 5-13/64 | 15/32 | 35/64 | 4.13 | 1/2 | UK209;HA2309 | FC209 | 2.83 |
| d (Inches) | a | e | i | g | s | z | t | B1 | p | j | k | f | Bolt Size mm inch | Bearing No. | Housing No. | Weight(kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 1-7/16 | 6-19/64 | 3-43/64 | 25/64 | 1-1/32 | 5/8 | 1-27/64 | 1-3/4 | 1.97 | 5-13/64 | 15/32 | 35/64 | 4.13 | 1/2 | UK209;HA2309 | FC209 | 2.83 |
